Inconel Alloy Inconel 602CA UNSN06025

Short Introduction:

HY 602CA/Inconel 602CA UNSN06025 /W. Nr./EN 2.4633/ERNiCrFe-12

HY 602 CA® alloy is the most oxidation resistant/high strength nickel alloy available. It is capable of extreme temperature use up to and beyond 2200°F (1200°C). For thermal processing applications where minimal product contamination is necessary, the oxidation/scaling resistance of RA 602 CA is extremely desirable. A high chromium content, along with aluminum and yttrium additions, allows the alloy to develop a tightly adhering oxide scale.

A relatively high carbon content combined with the alloying additions of titanium and zirconium results in high creep rupture strength. RA 602 CA provides 150% of the strength of other commonly used nickel alloys such as alloy 600.

Fob price: US $ 25 - 80 / Kilogram

Min.order quantity: 300kg

Port: Shanghai

Payment terms: L/C,T/T,30% down payment after order, balance against copy of B/L

Send email to us Download as PDF

Product Detail

Product Tags

HY 602CA Material grades and equivalents

Inconel 602CA UNSN06025 /W. Nr./EN 2.4633/ERNiCrFe-12

HY 602CA Chemical composition:

	Cr	Ni	C	Al	Ti	Y	Zr	Mn	Si	Cu	Fe
MIN	24.00		0.15	1.80	0.10	0.05	0.01	–	–	–	8.00
MAX	26.00	Balance	0.25	2.40	0.20	0.12	0.10	0.15	0.50	0.10	11.00

Specifications：

Rod, Bar, Wire and Forging Stock	ASTM B166; ASME SB166
Plate, Sheet and Strip	ASTM B168; ASME SB168

Regular shape for all kinds of alloys
Form	Specification	Supply Form	Others
Sheet	Thickness：0.40-4.75mm，General Width：1000、1219、1500mm	Whole Coil or piece of it	Cold Annealed，Surface 2B、2E
Plate	Thickness：4.76-60mm，Width：1500、2000、2500mm，Length：3000、6000、8000、8500mm（Under 10mm plate can be coiled）	Whole Coil or piece of it	Single hot rolling，Solid solution annealed state，Surface 1D
Belt	Thickness：0.10-3.0mm，Width：50-500mm	Whole Coil or Specified size	Cold Annealed，Surface 2B、2E
Bar & Rod	Rolled barΦ5-45mm，Length≤1500mm	Polished Bar（circle、Square）	Solution annealing,descaling
Bar & Rod	Forged barΦ26-245mm，Length≤4000mm	Polished Bar（circle、Square）	Solution annealing,descaling
Weld tube	Outer diameterΦ4.76-135mm，Wall Thickness0.25-4.00mm，Length：≤35000 mm	Base on your requirement
Seamless Tube	Outer diameterΦ3-114mm，Wall Thickness0.2-4.5mm	Base on your requirement
Wire	Outer diameterΦ0.1-13mm	Base on your requirement	Ni & Ni alloy, Ti & Ti alloy
Forged piece	discs,rings,squares,blocks,slabs	Base on your requirement	Steel, Alloy
Flangs	All kinds of Flangs	Base on your requirement	Steel, Alloy
Welding Material	Coil wire Φ0.025mm-1.6mm	Base on your requirement	Certificate of Origin：America, Sweden, Britain, Germany, Austria, Italy, France.
	Straight WireΦ1.6mm-4.0mm
	Welding rodΦ1.2mm-4.0mm
Tube	Elbow, three links, four links, different diameter size	Base on your requirement	Ni & Ni alloy, Ti & Ti alloy
Explosive bonded laminate	Raw Sheet Thickness≥2mm	Base on your requirement	Ni & Ni alloy, Ti & Ti alloy
