Nickel Alloy Inconel X-750 UNS N07750

\

Short Introduction:

인코넬 X-750 / GB GH4145 / UNS N07750 / W.Nr.2.4669 NiCr15Fe7TiAl / AFNOR NC15FeT이러한 가스 터빈, 제트 엔진 부품, 원전 애플리케이션 열처리 치구 형성 툴, 압출 다이 고온 구조 부재 등의 애플리케이션에 사용 된 석출 경화형 합금이다. 합금은 화학적 부식 및 산화에 매우 저항력이 높은 스트레스 파열 강도와 최대 1500 ° F (816 °에 C)에 적합한 열처리 후의 온도에서 높은 응력 하에서 낮은 크리프 속도를 가지고있다.


  • Fob price: US $ 25 - 80 / Kilogram
  • Min.order quantity: 300kg
  • Port: Shanghai
  • Payment terms: L/C,T/T,30% down payment after order, balance against copy of B/L
  • Product Detail

    Product Tags

    HY X-750 재질 등급과 동등

    인코넬 X-750 / GB GH4145 / UNS N07750 / W.Nr.2.4669 NiCr15Fe7TiAl / AFNOR NC15FeT

     HY X-750 화학 성분 :

    Alloy

    %

    Ni

    Cr

    Fe

    Nb

    Co

    C

    Mn

    Si

    S

    Cu

    Al

    Ti

    HY X-750

    Min.

    14

    5

    0.7

    0.4

    2.25

    Max.

    70

    17

    9

    1.2

    1

    0.08

    1

    0.5

    0.01

    0.5

    1

    2.75

    HY X-750 물리적 특성 :

    Density

    8.28 g / cm3

    Melting range

    1,393에서 1,427 사이 ℃

    HY X-750 합금 m의 inimum 실내 온도에서 기계적 성질 :

    Alloy

    Tensile strength
    Rm N/mm2

    강도 RP0.2N / mm2 인 항복

    ElongationA5 %

    브리넬 경도 HB

    Solution treatment

    1267

    868

    25

    ≤400

    HY X-750 특징 아래와 같이 :
    HY X-750은 가스 터빈, 제트 엔진 부품, 원전 애플리케이션 열처리 치구 형성 툴, 압출 다이 고온 구조 부재 등의 애플리케이션에 사용 된 석출 경화형 합금이다. 합금은 화학적 부식 및 산화에 매우 저항력이 높은 스트레스 파열 강도와 최대 1500 ° F (816 °에 C)에 적합한 열처리 후의 온도에서 높은 응력 하에서 낮은 크리프 속도를 가지고있다.

    HY X-750의 기계 가공성 :
    철계 합금의 가공에 사용되는 종래의 기술이 사용될 수있다. 이 합금은 업무 강화 가공 중에 수행하고 높은 강도와 ​​"점착성"철강의 전형적인하지 있습니다. 중부 가공 장비 및 도구는 앞서 절단의 합금의 잡담이나 가공 경화를 최소화하기 위해 사용되어야한다.
    HY X-750의 부식 저항 :
    HY X-750은 염소 이온 응력 부식 균열에 대한 우수한 저항이있다. 그것은 수많은 산화 환경에 만족 저항을 나타낸다. 합금은 여러 매체 (600) 합금과 유사한 내식성을 갖는다.
    HY X-750의 적용 범위 및 분야

    • 원자로
    • 가스 터빈
    • 로켓 엔진
    • 압력 용기



    Specifications:

    Plate

    AMS 5542/ASM 5598/Mil-N-7786

    Forgings

    AMS 5667/AMS 5668/AMS 5669/AMS 5670/AMS 5747/AMS B-637



    항공기 구조

    Regular shape for all kinds of alloys
    Form Specification Supply Form Others
    Sheet Thickness:0.40-4.75mm,General Width:1000、1219、1500mm Whole Coil or piece of it Cold Annealed,Surface 2B、2E
    Plate Thickness:4.76-60mm,Width:1500、2000、2500mm,Length:3000、6000、8000、8500mm(Under 10mm plate can be coiled) Whole Coil or piece of it Single hot rolling,Solid solution annealed state,Surface 1D
    Belt Thickness:0.10-3.0mm,Width:50-500mm Whole Coil or Specified size Cold Annealed,Surface 2B、2E
    Bar & Rod Rolled barΦ5-45mm,Length≤1500mm Polished Bar(circle、Square) Solution annealing,descaling
    Forged barΦ26-245mm,Length≤4000mm
    Weld tube Outer diameterΦ4.76-135mm,Wall Thickness0.25-4.00mm,Length:≤35000 mm Base on your requirement
    Seamless Tube Outer diameterΦ3-114mm,Wall Thickness0.2-4.5mm Base on your requirement
    Wire Outer diameterΦ0.1-13mm Base on your requirement Ni & Ni alloy, Ti & Ti alloy
    Forged piece discs,rings,squares,blocks,slabs Base on your requirement Steel, Alloy
    Flangs All kinds of Flangs Base on your requirement Steel, Alloy
    Welding Material Coil wire Φ0.025mm-1.6mm Base on your requirement Certificate of Origin:America, Sweden, Britain, Germany, Austria, Italy, France.
    Straight WireΦ1.6mm-4.0mm
    Welding rodΦ1.2mm-4.0mm
    Tube Elbow, three links, four links, different diameter size Base on your requirement Ni & Ni alloy, Ti & Ti alloy
    Explosive bonded laminate Raw Sheet Thickness≥2mm Base on your requirement Ni & Ni alloy, Ti & Ti alloy
